8x100M SFP Ports + 1x1000M SFP Port /TP Port (Combo) uplink Fiber Switch
SFP Fiber Switch Overview
The E-Link LNK-FS800 is a 9-port, unmanaged, 100 Mbps, all-optical fibre switch designed
for high-performance, reliable network connectivity. It features 8 SFP fibre ports for flexible fibre access
and one Gigabit Combo port supporting both 1000M SFP and 10/100/1000M adaptive RJ45 Ethernet
for efficient uplink. Support for SFP module hot-plugging enables seamless integration
with fibre switches, converters and other fibre-enabled devices. This switch is ideal for security,
electrical and traffic systems, ensuring stable and adaptable operation in diverse professional environments.
SFP Fiber Switch Features
►Supports up to 8 SFP fiber ports and 1 GE Combo port (interchangeable between SFP fiber and RJ45)
►Hot-pluggable SFP support for flexible and efficient installation
►Each port supports full-rate, full-duplex, non-blocking forwarding for high-performance data transmission
►8K MAC address learning with 1Mbit storage and forwarding cache, ensuring efficient data handling
►4.6G backplane bandwidth for seamless communication across the system
►Can replace central fiber converters, simplifying network architecture, reducing setup costs, and enhancing reliability
►Optimized for strong anti-interference capabilities across all optical ports, ensuring stable
and secure network performance
SFP Fiber Switch Technical Indexes
| Parameter | Specification |
| Standard | IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree |
| Wavelength | 850nm/1310nm/1550nm |
| Distance | 100M SFP: Depending on SFP Module Cat5:100m |
| Port | 8 SFP fiber ports: 100Mbps 1 Gigabit Combo port:1 Gbps, 1000M SFP&10/100/1000M RJ45 |
| MAC | 8K |
| Buffer memory space | 1Mbit |
| Bit error rate | <1/1000000000 |
| MTBF | 100000 hours |
| Power | DC12V/2A (DC12-48V) |
| Power consumption | 10W |
| Working temperature | -10~60℃ |
| Storage temperature | -40~80℃ |
| Humidity | 5%~90% non-condensing |
| Dimension | 28mm (H)×193mm(W)×119mm (D) |
SFP Fiber Switch Ordering Information
|  Item
| Description |
| LNK-FS800 | 9-ports Unmanaged Fiber Switch: 8x100M SFP ports + 1x1000M SFP port (Combo) uplink + 1x10/100/1000M RJ45 TP port (Combo) uplink, SFP slot supports 100BASE-SFP, not include SFP modules, External Power DC12V |
SFP Fiber Switch Application
